Specifications

• Dimensions

  add remove
  • Length:
    2225 mm
  • Seat height, laden:
    785 mm
  • Seat height, unladen:
    825 mm
  • Ground clearance:
    165 mm
  • Rake:
    24°
  • Trail:
    92 mm
  • Wheelbase:
    1465 mm
  • Tires, front specification:
    130/80-19 67H
  • Tires, rear specification:
    140/80-B19 71H
  • Tire, type:
    Dunlop® DT-1
• Power System & Charging

  add remove
  • High-voltage battery:
    10.5 KWH nominal
  • Charge plug:
    IEC TYPE 2
  • Level 1 20-80%:
    5.9 hours
  • Level 1 0-100%:
    8.4 hours
  • Level 2 20-80%:
    78 minutes
  • Level 2 0-100%:
    142 minutes
• Range

  add remove
  • Range, city:
    113 miles
  • Range, combined stop-and-go:
    86 miles
  • Range, highway:
    70 miles
• Performance

  add remove
  • Top speed:
    163 km
  • Electric motor torque:
    263 NM
  • Horsepower:
    84 HP / 63 KW
• Chassis

  add remove
  • Frame:
    Modular, with structural cast aluminum powertrain
  • Swingarm:
    Cast aluminium
  • Front fork:
    Showa® fully adjustable 43 mm inverted 1x1 cartridge forks
  • Rear shocks:
    Showa® free piston monoshock with progressive linkage, adjustable preload & rebound damping
  • Suspension travel:
    4.73 inch f/r
  • Wheel, front:
    19x3.0 10-spoke cast aluminum black
  • Wheel, rear:
    19x3.5 10-spoke cast aluminum black
  • Brakes, type:
    Brembo® monobloc front brakes
  • Brakes, caliper type:
    Brembo® m4.32 front monoblock 4-piston caliper, brembo® pf34 rear 1-piston floating caliper
  • Brakes, rotor type:
    Floating front disc, fixed rear disc
• Electric

  add remove
  • Lights (as per country regulation), indicator lamps:
    All LED, low beam, high beam and signature position lamp
  • Gauges:
    4 inch TFT colour display
• Infotainment

  add remove
  • LiveWire connect:
    Yes - app/phone supported
  • Screen type:
    Color TFT
  • Screen size:
    4 inch round
  • Voice recognition: phone functions only:
    Phone dependent
  • Voice recognition: tuner/media/navigation:
    Phone dependent
  • USB:
    USB-C
  • Bluetooth connectivity:
    Phone and media supported
